Materials
FR4 Tetrafunctional (140 Tg) • Multifunctional (170 Tg)
• Lead-Free (180 Tg)
• High-Performance FR408 • Polyimide
• Megtron • Nelco-13 • Rogers • Taconic

---

TECHNOLOGY
STANDARD
ADVANCED • Product Type

Rigid • Flex • Rigid-Flex
Maximum Panel Size
18" x 24"
21" x 24"

Maximum Board Size
16.5" x 22.5"
19.5" x 22.5"

Maximum Layers
16
32

Maximum Board Thickness
.125
.200 - .280

Minimum Core Thickness
.004
.002 - .001

Maximum Copper Weight
3 oz.
4 oz. - 8 oz.

---

Minimum Line Width / Spacing
.005 / .005
.003 / .003

Smallest Drilled Hole
.010
.008 - .005

Hole Aspect Ratio
10:1
12:1 - 14:1

Vias
Blind/Buried • Via in Pad • Metal/Epoxy Filled

---

Finishes
ENIG (Electroless Nickel / Immersion Gold
OSP Entek HT
Immersion Silver
Electrolytic Nickel / Gold
Horizontal Lead-Free HASL
​HASL
